Vision Transformer (ViT) - Notes

Table of Contents (ToC)

Introduction

ViT, or Vision Transformer, is a deep learning model that applies Transformer architecture to image classification tasks.

What's ViT?

  • Vision Transformer (ViT) adapts the Transformer model, originally designed for natural language processing, to the domain of computer vision.
  • It divides images into patches, treats them as sequences, and processes these sequences using Transformer encoders.

Key Concepts and Terminology

  • Patch Embeddings: Splitting an image into fixed-size patches and embedding them into a vector space.
  • Transformer Encoder: The core component that processes the sequence of image patches.
  • Positional Encoding: Adding position information to patches since the Transformer lacks intrinsic knowledge of order.
  • Self-Attention Mechanism: A key feature of Transformers that allows the model to focus on different parts of the image.

Applications

  • Image classification in various domains such as medical imaging, autonomous driving, and security.
  • Fine-grained image recognition tasks.
  • Transfer learning for specialized vision tasks.

Fundamentals

ViT Architecture Pipeline

  • Input image is divided into fixed-size patches.
  • Patches are linearly embedded and combined with positional encodings.
  • Embedded patches are processed through a stack of Transformer encoders.
  • The output of the Transformer is fed to a classification head for prediction.

How ViT works?

  • Patch Splitting: Divide the image into non-overlapping patches.
  • Linear Embedding: Flatten each patch and linearly project it into a lower-dimensional space.
  • Positional Encoding: Add positional information to each patch embedding.
  • Transformer Encoding: Process the sequence of patches through multiple layers of Transformer encoders.
  • Classification Head: Use the final output of the Transformer for classification tasks.

Some hands-on examples

  • Image classification on the CIFAR-10 dataset.
  • Transfer learning using pre-trained ViT on ImageNet.
  • Fine-tuning ViT for custom datasets.

Tools & Frameworks

  • TensorFlow: Implementations of ViT using TensorFlow.
  • PyTorch: PyTorch libraries and models for ViT.
  • Hugging Face Transformers: Pre-trained ViT models and fine-tuning tools.
  • JAX/Flax: JAX and Flax implementations for high-performance training.

Hello World!

from transformers import ViTFeatureExtractor, ViTForImageClassification
from PIL import Image
import requests

# Load the model and feature extractor
model = ViTForImageClassification.from_pretrained('google/vit-base-patch16-224')
feature_extractor = ViTFeatureExtractor.from_pretrained('google/vit-base-patch16-224')

# Load an image from the web
url = 'https://example.com/path/to/your/image.jpg'
image = Image.open(requests.get(url, stream=True).raw)

# Preprocess the image
inputs = feature_extractor(images=image, return_tensors="pt")

# Perform inference
outputs = model(**inputs)
logits = outputs.logits

# Get the predicted class
predicted_class = logits.argmax(-1).item()
print("Predicted class:", predicted_class)

Lab: Zero to Hero Projects

  • Basic Image Classification: Train a ViT model from scratch on the MNIST dataset.
  • Transfer Learning Project: Fine-tune a pre-trained ViT model on a medical imaging dataset.
  • Custom Dataset Project: Use ViT for image classification on a custom dataset, including data preprocessing, training, and evaluation.
